Full Auto Japanese Tofu Sealing Machine

Full Automatic Japanese Tofu Pouch Filling and Sealing Machine is a popular flexible packaging solution widely used in the global liquid and semi-fluid packaging industry. This equipment features unique packaging design, diverse pouch shapes, precise metering, strong sealing performance, simple operation and low packaging material cost.

It is widely applied in vacuum-free filling and packaging to prevent secondary pollution, ideal for dairy drinks, beverages, condiments, edible oil, daily chemicals and various liquid & semi-fluid products.

Equipped with imported pneumatic components and intelligent PLC control system, the machine realizes quantitative filling, automatic pouch forming, precise sealing and continuous running.

Main Features:

Suitable for automatic pouch filling and sealing for liquids and semi-fluids: Japanese tofu, egg tofu, soybean milk, milk, yogurt, jelly, fruit juice, soy sauce, vinegar, wine, cooking oil, liquid detergent and industrial liquid products. Stable performance and high recognition by global customers.

Humanized touch screen operation panel.

Intelligent: PLC control system.

Dual language display: Chinese and English.

Automatic pneumatic control system for stable running.

Button & touch screen integrated control: adjust filling volume digitally for accurate dosing and easy operation.

Equipped with professional pressure filling pump, avoiding material blockage, low efficiency and high air consumption of traditional pump structure.

Dual adjustment system with temperature and time control, solving sealing difficulty for special shaped pouches.

Stable mechanical operation, low failure rate and long service life.

Simple daily operation and convenient maintenance.

Special customized filling nozzles to ensure uniform and consistent sealing effect.

Technical Specifications (6 Heads, Single Operator):

Rated Power: 1.6KW

Production Speed: 3000-3200 pouches per hour

Air Consumption: 1.25-1.5m³/min

Working Air Pressure: 0.6-0.8Mpa

Filling Volume: 50ml - 1000ml (adjustable)

Working Voltage: 220V, 50HZ

Machine Dimension: 2450×2250×2500mm

Total Weight: 1000KG
