1. All stainless steel structure, combined or open transparent silo, easy to dismantle and wash without tools;

2. Servo motor and servo drive control screw;

3.Pneumatic bag clamping device and bracket on the weight sensor, according to the pre-set weight, fast and slow filling, high reaction speed weighing system, to ensure high accuracy;

4. PLC control, touch screen man-machine interface display, easy operation;

5. The two working modes can be switched, quantitative type or real-time weighing type. The quantitative type has fast speed and slightly worse accuracy, while the real-time weighing type has high accuracy and slower speed.

6. The formula for adjusting parameters of various products can be stored for later use, up to 10 formulas can be stored;

7. Replace the screw accessories, which can adapt to various materials from ultrafine powder to small particles.

Type

 CJSL25K/CJD50K-WL25K

Measurement methods

Weighing feedback tracking rotary backfill type

Weighing range

5KG-25KG（Changing screw attachment）

Filling accuracy

200g-1000kg  ≤±2g  ≥±1000kg   ≤±0.2%

Filling speed

5-25times/min

Power supply

Three phase380V  50-60HZ

Engine power

3KW

Whole machine weight

450KG

Whole machine volume

L1150*W1000*H2550

Bin volume

100L
